lt is suitable for the joining of furniture panels, straight panels, laminated timber. And wooden door cabinet core panels. And wooden door edge sealing, L-shaped door cover line joining,etc. Short board, long board, thick board, thin board, super thick board, red wood board, door line,door frame.
| Model | |||||
| Power supply | AC380V,50Hz | AC380V,50Hz | AC380V,50Hz | AC380V,50Hz | AC380V,50Hz |
| HF power | 20KW | 30KW | 40KW | 50KW | 60KW |
| HF frequency | 6.78-13.56MHz | 6.78-13.56MHz | 6.78-13.56MHz | 6.78-13.56MHz | 6.78-13.56MHz |
| Processing size | 2500×1300mm | 3200×1300mm | 4200×1300mm | 5200×1300mm | 6200×1300mm |
| Processing thickness | 8-80mm | 8-80mm | 8-80mm | 8-80mm | 8-80mm |
| Vertical pressure | 20T | 20T | 40T | 40T | 50T |
| Lateral pressure | 36T | 48T | 60T | 72T | 90T |
| Feeding and discharging way | Chain conveyor / Roller table | ||||
Tips: Fill in the message before you can get the product parameter manual
