| Model | OM-TS10S |
| Motor power | 2HP |
| Table size | 635mm x 430mm |
| With table extensions | 635mm x 1030mm |
| Saw blade / bore sizeф | 30mm arbor, 254mm dia. |
| Blade speed | 4750RPM |
| Maxdepth of cut at 90 degrees | 82mm |
| Maxdepth of cut at 45 degrees | 60mm |
| Cutting width with table extension | 750mm |
| Cutting width without table extension | 150mm |
| Coupling joint for vacuum exhaust ф | 65/25mm |
* Cast iron table and sliding table, 1500W induction motor fitted
