| Motor | 750W |
| Swing | 432mm |
| Chuck size | 3-16mm |
| Maximum drilling capacity | 25 |
| Taper | MT3 |
| Spindle travel | 120mm |
| 12 speeds | |
| Speed range (rpm)/50Hz | 150 to 2,700 |
| Speed range (rpm)/60Hz | 180 to 3240 |
| Overall height | 1700mm |
| Column diameter | 92mm |
| Working table | 345*345mm (350mm round table optional) |
